GWV Ball Nose Milling Cutter, Radius Precision Cutters

GWV Radius Precision Cutters

Add Inquiry
Product Specification
Item code Dimensions,mm Teeth Insert Screw Wrench Weight
KG
D d L L1
GWV12-S12-150 12 12 150 30 1 WPV 12-N-Slst MGR5012 ETL20 0.13
GWV16-S16-150 16 16 150 35 1 WPV 16-N-Slst MGR5016 ETL20 0.24
GWV16-S16-200 16 16 200 35 1 0.32
GWV20-S20-150 20 20 150 40 1 WPV 20-N-Slst MGR5020 ETL20 0.37
GWV20-S20-200 20 20 200 40 1 0.49



被切削材
Workpiece material		 Steel 鋼 P
Stainless steel 不鏽鋼 M
Cast iron 鑄鐵 K
Non-ferrous metal 非鐵金屬 N
Insert Shape Description GRADE 材質 Dimensions,mm
Coated 塗層
GA45 D
+0
-0.03		 S d1 L Re
WPV 12-N-Slst 12 2.5 5 14.0 1.0
WPV 16-N-Slst 16 3.0 5 16.0 1.0
WPV 20-N-Slst 20 3.0 5 18.0 1.6
WPV 25-N-Slst   25 4.0 6 23.5 2.0
